AGT55-226P
The gasifier AGT 55 - 226P is intended for gasification of liquid carbon dioxide, for gas consumption by production lines and for maintaining pressure in an isothermal tank at a flow rate of gas and liquid phases from it.
The gasifier consists of 2 columns of evaporators made of stainless steel 12X18H10T and 2 independent automatic control units.
Carbon dioxide evaporation heating occurs directly in the evaporator columns, which are shell-and-tube heat exchangers.
During the operation of the gasifier, the steam supply to each of the evaporator columns is automatically switched on and switched off in accordance with the signals from the temperature and pressure sensors, with which each of the evaporator columns is equipped.
The design of the gasifier with two columns of evaporators and two control systems reduces the heat retention of the gasifier
24 months warranty
| Working environment - liquid and gaseous carbon dioxide in accordance with GOST 8050 | |
| Heat carrier - steam | |
| CO2 gasifier productivity, kg / h, up to | 350 |
| Working pressure of CO2, MPa (kgf / cm2) | 2,5(25) |
| Working steam pressure, MPa (kgf / cm2) | 0,6(6) |
| Steam flow condition kg / h, up to | 170 |
| Vapor temperature °C, up to | +175 |
| Electric current voltage, V | 220 |
| Current frequency, Hz | 50 |
| The ambient temperature, °C | +5…+40 |
| Relative humidity, not more than,% | 80 |
| The mass of the gasifier, not more than, kg | 170 |
| Overall dimensions, mm: | 560х710х1500(h) |
