Reducing unit is mounted on vaporization line. It is designed to reduce and maintain gas pressure in preset limits when the gas is supplied from vaporizer or preheater to consumption line. Reducing unit capacity is no less than 400 kg/hr at preset pressure difference at the inlet and outlet no less than 3 kg/см².
Reducing unit body is made of stainless steel (12Х18Н10Т).
Warranty period: 24 months.
| Operating environment | CO2 in accordance with GOST (Russian State Standard) 8050 |
| Gas pressure at the inlet, kgf/cm² | up to 20 |
| Gas pressure at the outlet kgf/cm² | 2-12 |
| Maximum gas consumption, kg/hr | 400 |
| Ambient temperature, °C, no less | -30...+50 |
| Weight, kg, no more | 3,8 |
| Dimensions, mm, no more | 104х191х192 (h) |
| Connecting dimensions: | |
| - Inlet connection | pipe 25х2 stainless steel |
| - Outlet connection | pipe 25х2 stainless steel |
