AGT 141-01
Liquid CO2 Transfer Pump is used for transferring low pressure liquid CO2 from one vessel to another.
It has minimum dimensions and high capacity (10t/h), which allows its placement on-site near static storage tank (AGT 141- 01) or on transport equipment (AGT 141T).
The main construction units are mounted on the baseframe. The pumping unit has control panel and inlet and outlet fittings in sides of pump.
To connect vessels the unit is supplied with spiral metal hoses made of stainless steel:
- 2 items for “Liquid phase” (length – 2m, S70x4 to a tank, M48x2 to a pumping unit);
- 1 item for “Gas phase” (length – 4m, S70x4 to a tank from both sides).
The pump needs no lubrication, and its construction does not let any foreign substances in. Spare parts (an extra set of sealing and gaskets) and set of fixings are included.
Warranty period: 24 months.
| Operating environment | CO2 in accordance with GOST (Russian State Standard) 8050 |
| Nominal Capacity, ton/hr | 10 |
| Maximum head, m lift (kgf/cm²) | 60 (6) |
| Power consumption, kW, no more | 4 |
| Напряжение, В / Voltage, V | 380 |
| Working pressure, MPa (kgf/cm²): | |
| - Minimum | 0,8 (8,0) |
| - Maximum | 2,5 (25) |
| Liquid CO2 temperature, °C | -43,2…-11,31 |
| Manufacturing in accordance with GOST (Russian State Standard) 15150 | U1 |
| Габариты, мм / Dimensions, mm | 740 х 310 х 380 (h) |
| Масса, кг, не более / Weight, kg, no more | 120 |
| Присоединительные размеры: | |
| - вход / Inlet connection | М48х2-6g |
| - выход / Outlet connection | М48х2-6g |
