The systems AGT-26F, AGT-26F (5 kW) is designed to maintain preset pressure in liquid CO2 storage units as well as to liquefy carbonic acid gas. The pressure is maintained by CO2 freezing to avoid product loss during storage.
The refrigeration systems AGT-26F, AGT-26F (5 kW)consists of a condensing unit, a vaporizer, a control cabinet and junction pipes. The system automatically turns on when pressure reaches maximum level. Once pressure goes down to its minimum index, the system turns off. Thermostatic expansion valve controls Freon level in vaporizer and Freon boiling temperature.
Condensing unit and control panel are mounted directly on a storage unit and ready to be used without any additional installation works.
The systems AGT (АГТ) 26-2,5AGT, (АГТ) 26-2,5 (5 kW) is designed to maintain preset pressure in CO2 storage units and tanks by cooling and condensing carbonic acid gas.
The system AGT 26-2,5 is used in storage tanks and units of up to 22,5 m³ that do not have a system to maintain proper operating pressures. For tanks of more than 22,5 m³ refrigeration systems AGT 26-2,5 (5kW) with higher rating are available on request.
The system consists of a high quality scroll condensing unit “Copeland” and a high performance plate-type heat exchanger. Automatic control unit monitors the system performance according to preset operation parameters that conform to CO2 storage conditions of a tank. When the pressure decreases to a limit level, the refrigeration system turns off in standing by mode.
The system is connected to storage tank outlets “Liquid” and “Gas” with mounted adapters.
When delivered to consumer, condensing unit is filled with refrigerant. Freon and CO2 pipeline are molded which simplifies connection to a storage unit and start-up.
The system performance compensates external heat penetration in storage unit and ensures unlimited CO2 storage under proper operating pressure with no need to withdraw CO2.
Warranty period: 24 months.
